| Dimensions | 1280mm(L)×1190mm(W)×1050mm(H) | Weight | 310kg |
| Power Supply | AC220V (50Hz, single phase), 2.1kW | Air Supply | 0.5MPa ~0.7MPa |
| Vacuum Generation | Vacuum generator | Mounting Head Quantity | 4 |
| Mounting Speed | 10000cph(optimal) | Mounting Accuracy | ±50μm@μ±3σ/chip |
| Control Accuracy | 5μm | Component Height | 12mm |
| Component Type | 0201/0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc.
(resistor/capacitor/diode/triode/LED/IC, etc.) | PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 400mm(L)×350mm(W) | PCB Conveying | 3-section-rail automatic conveying |
| Nozzle Change | Automatic nozzle change (19-hole nozzle library) | Control System | Built-in industrial computer (Windows 7)
equipped with monitor, keyboard, and mouse |
| Drive System | X&Yaxisdriven by servo motors;adopting flexible S-curve acceleration and deceleration | Transmission System | Ball screw + linear guide |
| Feeding System | 50 Yamaha 8mm standard pneumatic/electric feeder stacks
(also suitable for IC tray and stick feeder) | Vision System | Snapshot camera×4 (component size applicable: 16mm×16mm);
IC camera×1 (component size applicable: 36mm×36mm);
Mark camera×2 |
